Highlights:
Specifications:
| Design | Designed as per ASME standards to comply the pressure in vessels and in Bio process. |
| Type | SS316L vessel with glass window and SS304 jacket, In-situ sterilizable(SIP &CIP) |
| Controls | Auto temperature/RPM:20-800/ pH/DO2 with cascade control/ Antifoam/Air flow/auto sterilization through Modular Micro-controller & PID Controls. Other probes for out-gases etc available on demand. |
| Drive | Top/bottom driven, direct coupled Motor with single/double mechanical seal. |
Steam/Air filtration | 0.22 µm PTFE filter Cartridge with SS316L housing plus 0.45/0.22µm prefilter with SS housing. |
Control Panel | Multi colored 5.7” TFT touch screen graphic display control panel for monitor/control the pH/Temp/DO and Agitation. |
Plate form/ Base frame | Suitable Platform/base frame. MOC: SS304/Powder coated MS to house the vessel, agitator assembly along with pipe rack etc. |
Other specfications and controls: | As above in Lab scale In-situ sterilizable(SIP&CIP)Fermenters/ Bioreactors. |
Software for Lab Scale to Pilot Scale Fermenters | Standard data acquisition software with RS-232-C serial port / USB Interface to communicate with PC for trends/graphs/Tabular form into Excel Format. Optionally SCADA software available for computer controlled fermenter operation |
Customized Design | Customized Fermenter vessels with higher capacities are provided with automation and control as per customer’s approved drawings available on demand up to 40K L capacity |
| Specifications | Descriptions |
|---|---|
| No Specifications | |
Brahmo offers a wide range of industrial equipment to satisfy the industrial needs of different aspects of the pharma industries.
